Our platform is crafted from durable aluminum with a sturdy plywood deck that is made with premium materials. The aluminum platform comes with side rails and cross bracing that are also made of high-quality aluminum alloy. Moreover, our plywood decks are built to cover the openings of scaffolds that are constructed using frame, bracing, or ringlock systems.
The platform's stability is maintained through the use of an aluminum wind clasp, even during the most severe weather conditions.
The boards are designed to be fully modular, making it easy to replace any piece using basic tools. One of the reasons why the boards are so durable is thanks to the extruded aluminum ribs and hooks that are overbuilt for maximum strength. Each hook is secured with four large bolts, ensuring that everything stays firmly in place. Overall, these boards are built to last and can withstand heavy use.
To minimize the risks of warping and tripping hazards, the work surface of all sizes is constructed using a single piece of plywood. Additionally, the side rails and rungs are manufactured from 6061 high-tensile aluminum.
Our scaffolding structures offer a stable work platform, tested at load capacities of 7-foot decks with 75 pounds per square foot and 10-foot decks with 50 pounds per square foot. This ensures a safe and secure environment for all construction activities.
|
Aluminum Platform with Plywood Deck |
|
|
Material: |
aluminum and plywood |
|
Length |
7' 8' 9' 10' (Customized Length) |
|
Standard |
ANSI,CSA,OSHA |
|
SWL |
For a 10-foot space, the minimum weight capacity is 75 pounds per square foot. However, for a 7-foot area, the weight capacity required is higher at 100 pounds per square foot. These weight limits must be considered in any construction project to ensure the safety and stability of the structure. With these guidelines in mind, builders can create a sturdy foundation for their projects, ensuring that they meet all necessary weight requirements and can withstand any potential stresses or strains. In short, weight capacity must always be a top consideration in any construction project, and accurate calculations must be made to ensure that the structure can safely support its intended load. |
|
Color |
1.47kg-1.67kg/Foot |
|
Surface |
Original Finish With Water-Proof Function |
|
Available Size |
||||
|
Width( inch) |
Length (inch) |
Length(mm) |
Weight(lbs) |
Dimension （H×W×L) |
|
19” |
25-1/2” |
647.7mm |
10 lbs |
4”×19”×2’ |
|
19” |
45” |
1143mm |
19 lbs |
4”×19”×4’ |
|
19” |
60” |
1524mm |
23 lbs |
4”×19”×5’ |
|
19” |
62” |
1574.8mm |
24 lbs |
4”×19”×5’2” |
|
19” |
84” |
2133.6mm |
32 lbs |
4”×19”×7’ |
|
19” |
120” |
3048mm |
46 lbs |
5”×19”×10’ |
|
24” |
60” |
1524mm |
26 lbs |
4”×24”×5’ |
|
24” |
84” |
2133.6mm |
37 lbs |
4”×24”×7’ |
|
24” |
120” |
3048mm |
53 lbs |
5”×24”×10’ |
Advantages of Aluminum Platform with Plywood Deck
1. High quality select plywood
2. Platform fits on most scaffolding brands.
3. Heavy duty aluminum construction
4. Anti pop-up sliding lock system at each end for added safety and security.
5. Aluminum wind latch to secure the platform even under severe wind conditions
Q1.What types of scaffolding planks did you produce?
Scaffolding Deck, Access platform with Ladder, Aluminium access deck, Aluminium access plank, Aluminium plank with Ladder, Aluminium board with ladder, Scaffolding platform with ladder.Scaffolding Ladder Access Deck
Q2.What are your main scaffolding products?
1. Ringlock scaffolding system
2. Frame scaffolding
3. Shoring Props
4. Steel Planks/Aluminum Planks/Plywood deck
5. Couplers and clamps
Q3.Why TOPSTAR Scaffolding?
For more than 10 years, Topstar Scaffolding has participated in big projects with well-known companies in Vietnam, Singapore, Peru, Qatar, UAE, and other countries.
Topstar has evolved from steel scaffolding into multiple core trades(steel and aluminum) over the years. We are providing ONE STOP scaffolding services ranging from including oil & gas, construction, petrochemical, marine, and insulation.
At Topstar, we have always formed a close partnership with our clients. We can provide timely execution of no matter big or small projects from start right to the end.
